| Item | Specification |
| Pin Number | 8 pins (male with protruding pins / female with concave holes) |
| Current / Voltage | 1–3A per pin @12V DC (4–5A customizable) |
| Contact Resistance | ≤ 50mΩ (gold-plated) |
| Mechanical Life | 10,000–100,000 mating cycles |
| Magnetic Force | 300–800g (anti-accidental disconnection) |
| Ingress Protection | IP65–IP68 (waterproof and dustproof) |
| Operating Temperature | -40℃ ~ +85℃ |
| Material | Gold-plated copper (pins) + Nylon / ABS (housing) + NdFeB magnet |
